ARCHITECTURAL STONEWORK PAVILIONS

“… at the ends and
extremities of a park are
beautiful pavilions of masonry,
which the French call
belvederes, or pavilions
of Aurora, which are as
pleasant to rest oneself in,
after a long walk, as they are
to the eye, for the handsome
prospect they yield; they serve
also to retire into for shelter
when it rains.”
Anon, XVIII century
Venetian Folly
L9400

The Venetian Folly, unveiled
at the Chelsea Flower Show
in 1990, has the classical
proportions of a Serlian window,
combining the use of Tuscan
columns, pedimented arch,
quoins and optional balustrading.
TS Tech Sheet No. T50
for L9400
TS Tech Sheet No. T51
for L9400 Detail
TS Tech Sheet No. T52
for L9400 Detail
TS CAD1 Column Assembly
Details
Venetian Folly L9400

5176 (203 ⁄4")
3
Ø1275 (50 ⁄16")
3

27.5°

4184 (164 ⁄4")
3
2620
(103 1 ⁄8")

7
1
4728 (186 ⁄8") 3186 (125 ⁄16") As required
to o.s. rail
FRONT ELEVATION SIDE ELEVATION

182 Custom-made products are available on request. Dimensions exclude joints. Allow 6mm ( ⁄4”) for joints.
